Form
Coil is uncoiled, flattened and helically formed into pipe, then tack welded.
Product range.
Complete project scope.
HSAW pipe, coatings, fabrication and logistics. Define the technical and commercial requirements in one conversation.
HSAW pipe.
Helical submerged arc welded steel pipe, manufactured to the dimensional, material and testing requirements of the project.
Our two-step mill supports API/ISO, ASTM and AWWA pipe requirements, including applications with sour-service requirements.
Standard lengths are available at 40, 60 and 80 feet. Discuss custom lengths and the combination of diameter, wall and grade with our team.
Review a specification| Outside diameter | 24–60 in. |
|---|---|
| Wall thickness | 0.312–1.00 in. |
| API 5L grades | Grade B through X80 |
| CSA Z245 grades | Up to L550 |
| Lengths | 40, 60 and 80 ft; custom lengths |
| Annual capacity | 300,000 tons |
| Additional specifications | ASTM, AWWA and sour-service requirements |
Availability depends on the combination of diameter, wall, grade and project requirements. Confirm your specification with our sales team.
Preparing a technical enquiry?
Include diameter, wall, grade, length, quantity, coating, delivery location and required schedule.
Prepare an enquiryFrom steel coil to finished pipe.
A two-step manufacturing route separates forming from final welding.
Weld
Inside and outside spiral seams are submerged arc welded on four welding lines.
Inspect
Welds and pipe bodies undergo inspections and testing to the applicable specification.
Finish & deliver
Coating, end preparation and delivery planning complete the project scope.
Dedicated welding capability.
Four submerged arc welding lines weld the internal and external spiral seams. Digital welding systems and optical seam tracking support the manufacturing process.
Hydrostatic testing, automated ultrasonic inspection and radiography support the requirements of the applicable order. The in-house laboratory performs mechanical and chemical evaluation.
See testing capabilitiesValue-added services.
Resolve more of the project scope before pipe leaves the mill.
Splicing & double jointing
Discuss joining requirements alongside the required pipe lengths.
Attachments
End plates, conical tips, drive shoes and lifting eyes for specified applications.
Additional finishing
Coal tar epoxy coating and selected minor fabrication, reviewed against the project scope.
Protection suited
to the service.
Coordinate external coating and internal lining with the operating environment, installation method and project specification.
Protection for the operating environment.
- Fusion Bonded Epoxy (FBE)
- Abrasion Resistant Overcoat (ARO)
- Coal Tar Epoxy (CTE)
Support for efficient flow.
- Flow Efficiency Epoxy Liner
- Coating scope reviewed against your specification
A practical route
to your project.
At Port Bienville Industrial Park, our location provides access to water, rail and road networks.
Barge
Private docks, vacuum lifting equipment and access to the Gulf Intracoastal Waterway and inland waterways.
Rail
Port Bienville Railroad connects the facility to CSX and the wider national rail network.
Truck
Access to I-10 and I-59, supported by a drive-on scale at the mill.
Turn requirements into a defined scope.
Bring us your specification, delivery requirements and questions. Our team will help you define the right scope.
